Haynes 25/L605 is a Cobalt-Nickel-Chromium-Tungsten alloy that combines good high-temperature strength with good resistance to oxidizing environments up to 980°C (1795°F) for long exposures. Some of the industries Haynes 25/L605 is supplied to include aerospace, power generation, electronics, land-based turbines and medical.
Alloy L-605 / Haynes 25 has many applications in commercial and military gas turbine engine components such as rings, blades and combustion chamber parts.
The chemical composition of Haynes 25/L605 is indicated in the table below.
C: 0.05% – 0.15%
Mn: 1.0% – 2.0%
Si: 0.4% max
P: 0.04% max
S: 0.03% max
Cr: 19.0% – 21.0%
Ni: 9.0% – 11.0%
W: 14.0% – 16.0%
Fe: 3.0% max
Co: Bal
L605 has provided good service in many jet engine parts and gas turbine components such as combustion chambers and afterburners. Other aerospace applications include:
